Features
Compact design
Smallest P25 Phase 2 TDMA-capable radio available.
Full-size keypad
Simple to navigate and use.
Color display
High-contrast color display is easy to read in all kinds of light.
Multifunction knob
The multifunction knob is designed for ease of use by combining volume, channel, and ON/OFF settings in one.
Dual microphones
Dual microphone noise suppression technology locates the talker and cancels out any background noise.
AMBE vocoder
Equipped with the latest AMBE +2 digital voice vocoder.
Three radio models
Three radio models allow the user to select the device that best suits the end users environment.
Intelligent lighting
Uses color to notify you of the radio mode, potential emergencies, or specific events. Color alerts provide information at a glance.
Radio profiles
Adjust audio levels, lighting and tones through user selected or automated options. Whether on surveillance or working in bright sunlight, you can customize settings as needed.
Text messaging
Offers a freeform or canned messaging solution so you can efficiently and discreetly send and receive messages.
Voice announcement
Audible, pre-recorded voice file provides a description of the selected channel or zone.
Over-the-air programming
Motorola’s POP25 solution allows subscriber radios to be programmed over the air via the ASTRO 25 systems while remaining in the field.
P25 Phase 2 - TDMA
Twice the voice capacity, allowing additional users on the system without the need for additional frequencies or infrastructure.
Specification Sheet
Performance Characteristics
-
Battery life (based on a 05 05 90 duty cycle)
8-10 hours
-
Battery life - extended (based on a 05 05 90 duty cycle)
10-12 hours
-
Channel spacing
6.25, 12.5, 25
-
Frequency band
700 MHz, 800 MHz, 900 MHz, UHFR2, UHFR1, VHF
-
Frequency bands
700/800 (763-776, 793-806, 806-824, 851-870 MHz)
900 (896-901, 935-940 MHz) Two-Knob Model Only
VHF (136-174 MHz)
UHF Range 1 (380-470 MHz)
UHF Range 2 (450-520 MHz) -
Standard battery chemistry type
Lithium Ion
Physical Characteristics
-
Dimensions H x W x D (without standard battery)
5.26" x 2.37" x 1.72"
-
Display
Full
-
Emergency button
Programmable
-
Weight
TBD
-
Weight (without standard battery)
8.22 oz.
Radio Features
-
Advanced Software Features
Integrated Voice and Data (IV&D), Programming Over P25
-
CPS (Customer Programming Software)
Yes
-
Noise reduction software
Yes
-
Number of channels
512
-
FLASHport memory
Yes
-
Time out timer
Yes
-
Status calls
Yes
-
Cloning
With multi-unit charger (MUC)
-
Channel scan
Yes
-
Voice announcement
Yes
Technology
-
System type
Conventional, SmartZone trunking, TDMA, Analog, Digital
User Environment
-
IP Standards
IP54
-
Mil spec
810 C, 810 D, 810 E, 810 F, 810 G
-
Operating temperature
-30ºC / +60ºC
-
Storage temperature
-40ºC / +85ºC
-
Water resistance
IP54 Standard
Warranty
-
Standard package
Yes
-
Standard warranty
3 years, 5 years
