Features
Transmit Interrupt Capability
Enables a user to interrupt another radio conversation to deliver critical communication exactly when and where it’s needed.
Over the Air Programming (OTAP)
Manages, writes and reads up to 5,000 radio configurations over the air.
Enhanced Privacy
Built-in scrambling for increased security.
Systems Capability
Experience the far-reaching coverage of MOTOTRBO. IP Site Connect uses the Internet to extend coverage to create a wide-area network, while Capacity Plus single-site trunking expands capacity to over 1000 users without adding new frequencies.
Compatible with Radio Management Suite
Program your radios quickly and efficiently, with the Radio Management tool. Radios can be programmed in batches to a standardized template, giving error-free results and optimized performance.
Intelligent Audio
Radio volume automatically adjusts to compensate for background noise so workers don’t have to adjust their radio volume to avoid missing a call in loud situations or disturbing others when they move into quiet places.
IMPRES Audio
Whether it’s a whisper during a covert operation in a dark alley or commanding a noisy fire scene, IMPRES audio accessories are loud, clear and intelligible in both analog and digital modes.
IP54 Rated
Protects your radio from dust and spills.
Performance Characteristics
-
Power output
1-25W, 25-45W - VHF, 1-25W, 25-40W - VHF
-
Frequency band
VHF, UHF
Physical Characteristics
-
Display
Monochrome
-
Weight
2.9 lbs (1.3kg)
-
Dimensions H x W x D
1.7 x 6.7 x 5.3 in (44 x 169 x 134 mm)
Radio Features
-
Call forward
Yes
-
Enhanced privacy
Optional
-
Transmit interrupt
Optional
-
Channels
128
-
Busy channel lockout
Yes
-
Call tones
Yes
-
Caller ID
Yes
-
Channel spacing
12.5
-
One-to-one calling
Yes
-
Talkaround
Yes
-
Time out timer
Yes
-
Programmable buttons
Yes
-
Intelligent audio
Yes
-
Signaling
MDC (Encode/Decode), Quik-Call II (Encode/Decode), DTMF Encode
-
Voice announcement
Yes
-
Lone worker
Yes
Technology
-
System type
Conventional, Capacity Plus, IP Site Connect
-
Digital technology
Yes
User Environment
-
IP Standards
IP54
-
Mil spec
810 C, 810 D, 810 E, 810 F, 810 G
