Features
Due to the FCC Narrowbanding mandate in the United States, product specifications and brochures for Motorola Solutions two-way radio products may indicate 25 kHz/12.5 kHz analog/digital operation which may not be the standard mode of operation at the time of shipment after Jan. 1st 2013.
Business-exclusive frequencies
27 VHF frequencies make signals extra-secure and exceptionally clear. 219 codes, including customized PL and DPL codes to help ensure a clear signal
Exceptional voice quality
Delivers increased clarity through wind-noise reduction.
Rugged and water-resistant
Meets military specifications for sealing against dust, wind, shock, vibration and other adverse conditions.
Customer programming software
Allows users to perform programming functions and access new features.
Bright sensors
Tricolor LED indicator shows feedback of calling or monitoring features.
Enhanced battery performance
Lithium-ion battery lasts longer, with no memory “over-charge” side effects.
Enhanced battery performance
Lithium-ion battery lasts longer, with no memory “over-charge” side effects.
Simplified cloning
Quickly copies settings from radio to radio when used with accessory.
Voice activation
Enables hands-free operation when used with accessory.
Disable Channel
Allows users to disable and skip undesirable channels via the customer programming software (CPS)
Channel Annunciation
Voice support for channel announcement
Repeater Capability
Compatible with duplex repeaters so you can significantly extend your radio coverage area
Dynamic Talkaround Scan
Allows the radio to automatically switch between repeater and talkaround modes in order to optimize communications.
Specification Sheet
Motorola RDX Series Data Sheet
RDX Series - Business Radio
Performance Characteristics
-
Adjustable power levels
Yes
-
4 5 Watt
Yes
-
Frequency band
VHF
-
Standard battery chemistry type
Lithium Ion
-
Estimated battery life
up to 18.5 hours
-
Power
5W
-
Coverage area
Up to 300,000 sq. ft. 18 floors
-
Repeater capable
Yes
Physical Characteristics
-
Dimensions H x W x D (with standard battery)
4.5 x 2.2 x 1.8
-
Weight (with standard battery)
10.3 oz
-
Display
No Display
-
Keypad
None
-
Emergency button
None
Radio Features
-
Channel scan
Yes
-
Number of channels
10
-
Channel spacing (kHz)
12.5
-
CPS (Customer Programming Software)
Yes
-
Time out timer
Yes
-
Voice operated transmit (VOX)
Yes
-
Programmable buttons
Yes
-
Cloning
With cable, With multi-unit charger (MUC)
Technology
-
System type
Conventional
User Environment
-
IP Standards
IP55
-
Mil spec
810 C, 810 D, 810 E, 810 F
-
Water resistance
Yes
Warranty
-
Standard warranty
2 years
