Features
Best-in-class Audio
Loud front-facing speaker and Intelligent Audio feature that automatically adjusts the radio volume according the environment’s noise level
Productivity-enhancing Data Applications
Features the industry’s largest application developer program to enable a wide variety of customised applications including: location tracking, email gateways, dispatch, telephony, man-down and work order ticket management
Capacity Plus
Single-site digital trunking system that maximises the capacity of your MOTOTRBO system. Use it to enable a high volume of voice and data communication for over a thousand users at a single site without adding new frequencies
Linked Capacity Plus
Linked Capacity Plus is a multi-site digital trunking system for the MOTOTRBO platform. It leverages the high capacity of Capacity Plus, with the wide area coverage capabilities of IP Site Connect to keep your staff at various locations connected with an affordable high-capacity, wide-area trunking solution
Rugged Design
Tightly sealed against wind and dust, and submersible in up to one meter of water for 30 minutes (IP67)
Emergency Button
Orange button on the top of the radio can be programmed to send an alert to a supervisor or dispatcher during an emergency situation
Integrated GPS (option)
Locate mobile work teams using integrated GPS
Text Messaging
Send preprogrammed update messages to team members when radio communications need to be delivered without interrupting workers or guests
IP Site Connect
A digital solution that uses the internet to extend the voice and data capabilities of MOTOTRBO. Use it to link up to 15 sites for communication among geographically dispersed locations, to create wide area coverage or enhance coverage at a single site with physical barriers
Basic or Enhanced Privacy
Built-in scrambling for increased security
Transmit Interrupt
Enables a user to interrupt another radio conversation to deliver critical communication exactly when and where it’s needed.
Specification Sheet
-
Mototrbo DP4000 Series Accessories Fact Sheet
DP4000 Ex Series ATEX/IECEx Accessory Solutions
-
Mototrbo DP4000 Series Product Spec Sheet
MOTOTRBO DP4000Ex Series Brochure
Performance Characteristics
-
Frequency band
VHF, UHF
-
Repeater capable
Yes
-
Battery life (based on a 05 05 90 duty cycle)
19 hours in digital mode, 16 hours in analogue mode
-
Standard battery chemistry type
Lithium Ion
-
1 Watt
Yes
Physical Characteristics
-
Emergency button
Yes
-
Keypad
None
-
Display
No display
-
Weight (with standard battery)
455.5g (16.1 oz)
-
Dimensions H x W x D (with standard battery)
138.5 x 56.7 x 37.8 mm (5.45 x 2.23 x 1.49 in)
Radio Features
-
Transmit interrupt
Yes
-
Digital private line
Yes
-
Private line
Yes
-
Monitor Permanent (Sticky) Monitor
Yes
-
Lone worker
Yes
-
GPS capable
Yes
-
Voice announcement
Yes
-
Signalling
Signalling 5-tone, MDC (Encode/Decode), Quik-Call II (Encode/Decode), DTMF Encode
-
Intelligent audio
Yes
-
Programmable buttons
Yes
-
Voice operated transmit (VOX)
Yes
-
Time out timer
Yes
-
Talkaround
Yes
-
Text messaging capable
Yes
-
Scan types
Normal, Priority, Dual priority, Nuisance channel delete, Talk group, All group, System, Home revert
-
Phone book
Yes
-
Group call
Yes
-
One to one calling
Yes
-
Missed call alerts
Yes
-
CPS (Customer Programming Software)
Yes
-
Channel spacing
12.5, 25, 20
-
Number of channels
64
-
Channel scan
Yes
-
Call tones
Yes
-
Call forward
Yes
-
Busy channel lockout
Yes
-
Integrated voice and data
Yes
Technology
-
System type
TDMA, Capacity Plus, Linked Capacity Plus, IP Site Connect
-
Digital technology
Yes
User Environment
-
ATEX IECEx
Yes
-
Submersible
Yes
-
Intrinsically safe
Yes
-
Mil spec
810 C, 810 D, 810 E, 810 F, 810 G
-
Noise reduction software
Yes
-
IP Standards
IP67
Warranty
-
Standard warranty
2 years
