Features
Connected
The MOTOTRBO DP4000e Series is a family of DMR standard digital radios that delivers operations-critical voice and data communications. Bluetooth® audio lets you talk without wires, integrated Wi-Fi enables remote software upgrades and indoor and outdoor location- tracking capabilities give you total visibility of your resources. With support for trunking as well as legacy analog technology, you can keep your organization connected as it grows.
Productive
Text messaging and Work Order Ticketing simplify complex communications, and data capabilities support advanced applications. Featuring a powerful audio amplifier, these radios deliver loud, clear speech, with industrial noise cancellation for better intelligibility. The latest energy technology delivers up to 28 hours of battery life for 3-shift working, and an improved receiver boosts range by up to 8%.
Safe
Safeguard your staff with responsive push-to-talk technology.The prominent orange emergency button on DP4000e Series radios summons help with one touch, using Transmit Interrupt to pre- empt to clear a channel when necessary. An integrated accelerometer senses if you’ve fallen and can automatically call for assistance. The radio is tested to tough military standards and is waterproof to IP68. It won’t let you down.
Specifications
Performance Characteristics
-
Frequency band
UHF, VHF, 800 MHz, 900 MHz
-
4 5 Watt
Yes
-
Repeater capable
Yes
-
Battery life (based on a 05 05 90 duty cycle)
Digital/Analog Battery Life, High Capacity 2250 mAh Battery:
DP4800/DP4801 VHF: 22/16.5 hours
DP4800/DP4801 UHF: 21/16 hours
DP4800/DP4801 800: 21/17.5 hours
DP4601 VHF: 22/16.5 hours
DP4601 UHF: 21/16 hours
DP4400/DP4401 VHF: 22/16.5 hours
DP4400/DP4401 UHF: 21/16 hours
DP4401 800: 21/17.5 hours
Digital /Analog Battery Life, High Capacity, Low Voltage 3000 mAh Battery:
DP4800/DP4801 VHF: 29/22 hours
DP4800/DP4801 UHF: 28/21.5 hours
DP4800/DP4801 800: 28/23 hours
DP4601 VHF: 29/22 hours
DP4601 UHF: 28/21.5 hours
DP4400/DP4401 VHF: 29/22 hours
DP4400/DP4401 UHF: 28/21.5 hours
DP4401 800: 28/23 hours -
Standard battery chemistry type
Lithium Ion
-
1 Watt
Yes
Physical Characteristics
-
Available option board
Yes
-
Emergency button
Yes
-
Display
Full, Color
-
Weight (with standard battery)
DP4800e and DP4801e : 347 g
DP4601e : 347 g
DP4400e and DP4401e : 322 g -
Dimensions H x W x D (with standard battery)
DP4800e and DP4801e : 130 x 55 x 36 mm
DP4601e : 130 x 55 x 36 mm
DP4400e and DP4401e: 130 x 55 x 34 mm
Radio Features
-
Enhanced privacy
Yes
-
Transmit interrupt
Yes
-
Digital private line
Yes
-
Private line
Yes
-
Monitor Permanent (Sticky) Monitor
Yes
-
Lone worker
Yes
-
GPS capable
-
Voice announcement
Yes
-
Signalling
MDC (Encode/Decode), Quik-Call II (Encode/Decode)
-
Intelligent audio
Yes
-
Bluetooth
Integrated Bluetooth audio, Integrated Bluetooth data
-
Programmable buttons
Yes
-
Voice operated transmit (VOX)
Yes
-
Time out timer
Yes
-
Talkaround
Yes
-
Text messaging capable
Yes
-
Scan types
Normal, Priority, Dual priority, Nuisance channel delete, Talk group, All group, System, Home revert
-
Phone book
Yes
-
Group call
Yes
-
One to one calling
Yes
-
Missed call alerts
Yes
-
CPS (Customer Programming Software)
Yes
-
Channel spacing
12.5, 25
-
Number of channels
DP4800/DP4801 - 1000 channels
DP4601 - 1000 channels
DP4400/DP4401 - 64 channels -
Channel scan
Yes
-
Caller ID
Yes
-
Call tones
Yes
-
Call forward
Yes
-
Busy channel lockout
Yes
-
Integrated voice and data
Yes
Technology
-
System type
Conventional, IP Site Connect, Capacity Plus, Connect Plus Trunking
-
Digital technology
Yes
User Environment
-
Submersible
Yes
-
Factory Mutual
Yes
-
Intrinsically safe
Yes
-
Mil spec
810 C, 810 D, 810 E, 810 F, 810 G
-
Noise reduction software
Yes
-
IP Standards
IP57
-
Warranty
-
Standard warranty
2 years
